Expert II Series is the best choice for beginners and provides sign makers with optimum speed, superior quality, solid reliability and unmatched value. Expert II produces eye-catching graphics with up to 27.8 ips (25 ips for EX-52 models ) cutting speed, 350g of cutting force and three meters (9.84 feet) of tracking ability. The versatile Expert II Series sets a new benchmark for value, offering high accuracy and reliability at an unbelievably affordable price.
| Expert II Series | C-24LX | C-48LX | C-59LX | |
|---|---|---|---|---|
| Media way | Floor Stand (Optional) | Floor Stand | Floor Stand | |
| Control Panel | 11 silicon buttons,2.4 inch screen | |||
| Driver | High speed, big power step motor,micro-step driver | |||
| Maximum paper feed width | 740mm | 1310mm | 1660mm | |
| Maximum cutting width | 630mm | 1205mm | 1550mm | |
| Maximum cutting speed | 800mm/s | |||
| Cutting Force | 10-500g (Digital adjustment) | |||
| Mechanical Precision | 0.025mm | |||
| Repeatable Precision | <±0.025mm | |||
| Power Supply/Consumption | AC 220V/110V, 50-60HZ , <80W | |||
| Plotter Instruction | Compatible DM/PL, HP/GL | |||
| Control Panel | 11 Backlist silicon buttons | |||
| Interface | USB/U disk / Serial Port | |||
| Type of Plotter Pen | All types diameter 11.4mm plotter pen | |||
| Power Supply | AC220V / 110V,50~60Hz | |||
| Power consumption | <80W | |||
| Knife(blade) | TENETH imported blade | |||
| Operating environment | Temperature :5-35℃, Relative Humidity: 30%～70% | |||
| Package size | 1060*340*400mm | 1590*340*400mm | 1900*340*400mm | |
| Gross weight | 22 KG | 35 KG | 40 KG | |
