*Far Infrared Blackbody Tube Radiation Electro thermal Heating
*Intelligent PID Temperature Control
*Digital Tension Control
*Feeding and Taking up Are synchronous
*Vacuum Fan Delivery Is Controllable
*Quick Tail Gas Treatment
*Convenient to Maintain
*Easy to Set up and Operate·Easy to load the media in and out oven during your machine working
*Easy to open the caver to clean inside of oven
*Special clutch to control the feeding up system working or stop , it’s ·easy for you loading the roll materials.
*Easy to change the active carbon from the filter
*Adopting the most advanced thermal energy technology low power consumption, saves electricity and conserve energy costs
*High Productivity
| Power | 3.8KW | |
|---|---|---|
| Working Width | 1800MM | |
| Blackbody Tube Working Model | Far Infrared | |
| Heat Tuble Dimension | 2220MM | |
| Working Temperture | 100 to 250 °C | |
| Tension | 0 to 1.2Kg | |
| Working Voltage Take Up working Method Take Up media diameter(roll to roll) | 220~240V 50HZ Directly out or Roll to Roll. 300mm | |
| Machin package Dimension | 2780X1330X870mm | |
| Weight | 320Kg | |
| Certification | CE Certificated | |
| Package | High intensity standard carton package Non Fumigation | |
| Available Printer | Mimaki, Roland , Mutoh and any Piazo Printer | |
